میکروکنترلر PIC18LF6621
میکروکنترلر PIC18LF6621 میکروکنترلر پیشرفته از شرکت Microchip مبتنی بر معماری 8-bit از PIC® ، با ساختار حافظه فلش بر مبنای CMOS و زمان اجرای هر دستور به طول 200 نانو ثانیه دارای ویژگی های 64KB کیلوبایت حافظه فلش ، 3.8KB بایت حافظه SRAM ،کیلوبایت 1KB حافظه EEPROM و 5 تایمر کانتر چند منظوره با قابلیت حالت مقایسه و pwm ، دو پروتکل ارتباطی USART ، مبدل آنالوگ به دیجیتال 12 کانال 10 بیتی ، رابط SPI ، رابط 2-wire ، دو مقایسه کننده ، می باشد که این پردازنده را تبدیل به میکروی کاربردی در انواع پروژه های پیشرفته کرده است.
کاربردها
-
- پروژه های عمومی الکترونیک
- اتوماسیون
- اینترنت اشیاء
- کنترل
- درایو انواع موتور ها
- سیستم های ابزار دقیق
- رباتیک
ویژگیهای محصول
با توجه به اهمیت مطالب فنی از ترجمه صرف نظر شده است.
High Performance RISC CPU: • Linear program memory addressing to 64 Kbytes • Linear data memory addressing to 4 Kbytes • 1 Kbyte of data EEPROM • Up to 10 MIPs operation: – DC – 40 MHz osc./clock input – 4 MHz – 10 MHz osc./clock input with PLL active • 16-bit wide instructions, 8-bit wide data path • Priority levels for interrupts • 31-level, software accessible hardware stack • 8 x 8 Single-cycle Hardware Multiplier Peripheral Features: • High current sink/source 25 mA/25 mA • Four external interrupt pins • Timer0 module: 8-bit/16-bit timer/counter • Timer1 module: 16-bit timer/counter • Timer2 module: 8-bit timer/counter • Timer3 module: 16-bit timer/counter • Timer4 module: 8-bit timer/counter • Secondary oscillator clock option – Timer1/Timer3 • Two Capture/Compare/PWM (CCP) modules: – Capture is 16-bit, max. resolution 6.25 ns (TCY/16) – Compare is 16-bit, max. resolution 100 ns (TCY) – PWM output: 1 to 10-bit PWM resolution • Three Enhanced Capture/Compare/PWM (ECCP) modules: – Same Capture/Compare features as CCP – One, two or four PWM outputs – Selectable polarity – Programmable dead time – Auto-Shutdown on external event – Auto-Restart • Master Synchronous Serial Port (MSSP) module with two modes of operation: – 2/3/4-wire SPI™ (supports all 4 SPI modes) – I2C™ Master and Slave mode • Two Enhanced USART modules: – Supports RS-485, RS-232 and LIN 1.2 – Auto-Wake-up on Start bit – Auto-Baud Rate Detect • Parallel Slave Port (PSP) module |
External Memory Interface (PIC18F8525/8621 Devices Only): • Address capability of up to 2 Mbytes • 16-bit interface Analog Features: • 10-bit, up to 16-channel Analog-to-Digital Converter (A/D): – Auto-Acquisition – Conversion available during Sleep • Programmable 16-level Low-Voltage Detection (LVD) module: – Supports interrupt on Low-Voltage Detection • Programmable Brown-out Reset (BOR) • Dual analog comparators: – Programmable input/output configuration Special Microcontroller Features: • 100,000 erase/write cycle Enhanced Flash program memory typical • 1,000,000 erase/write cycle Data EEPROM memory typical • 1 second programming time • Flash/Data EEPROM Retention: > 100 years • Self-reprogrammable under software control • Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST) • Watchdog Timer (WDT) with its own On-Chip RC Oscillator for reliable operation • Programmable code protection • Power-saving Sleep mode • Selectable oscillator options including: – 4x Phase Lock Loop (PLL) – of primary oscillator – Secondary Oscillator (32 kHz) clock input • In-Circuit Serial Programming™ (ICSP™) via two pins • MPLAB® In-Circuit Debug (ICD 2) via two pins CMOS Technology: • Low power, high-speed Flash technology • Fully static design • Wide operating voltage range (2.0V to 5.5V) • Industrial and Extended temperature ranges |
