• STM32F746NGH6 Arm® Cortex® core-based microcontroller with 1 Mbyte of

Flash memory and 340 Kbytes of RAM, in BGA216 package

• 4.3” RGB 480×272 color LCD-TFT with capacitive touch screen

• Ethernet compliant with IEEE-802.3-2002

• USB OTG HS

• USB OTG FS

• SAI audio codec

• Two ST-MEMS digital microphones

• 128-Mbit Quad-SPI Flash memory

• 128-Mbit SDRAM (64 Mbits accessible)

• Two user and reset push-buttons

• Board connectors:

– Camera

– microSD™ card

– RF-EEPROM daughterboard connector

– 2×USB with Micro-AB

– Ethernet RJ45

– SPDIF RCA input connector

– Audio line in and line out jack

– Stereo speaker outputs

– ARDUINO® Uno V3 expansion connectors

• Flexible power-supply options: ST-LINK, USB VBUS or external sources

• Power supply output for external applications: 3.3 V or 5 V

• Comprehensive free software libraries and examples available with the

STM32Cube MCU Package

• On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration

capability: mass storage, Virtual COM port, and debug port

• Support of a wide choice of Integrated Development Environments (IDEs)

including IAR™, Keil®, GCC-based IDEs, and Arm® Mbed™
