Product model: AYN-MF59-104F-3950FB

The main technical parameters:

۱٫ Resistance (R25 ° C): 100 KΩ

۲٫ Resistance (R25 ° C) allowable deviation: ± ۱%

۳٫B value: 3950K

۴٫ B value tolerance: ±۱%

۵٫ Operating temperature range: -40 ° C ~ 250 ° C

۶٫ Dissipation coefficient: ≥۲mW/°C (in still air)

۷٫ Time constant: ≤ ۲۰S (in still air)

۸٫ Structural package: single-ended lead glass package

۹٫ Dimensions (pictured) : unit (mm)

Head 1.8mm single-end glass seal: recommended opening size φ۲mm

Product application range:

۱٫ Induction cooker, electric pressure cooker, disinfection cabinet, water dispenser, microwave oven, electric heating stove and other household appliances temperature control and temperature detection.

۲٫ Temperature detection and temperature compensation of office automation equipment (copiers, printers, fax machines, 3D printers, program-controlled machines, etc.).

۳٫ Industrial, medical, environmental, meteorological, temperature control and testing of food processing equipment.

۴٫ Temperature protection of communication products such as mobile phone battery packs and chargers.

۴٫ Instrument coil, integrated circuit, quartz crystal oscillator and thermocouple temperature compensation.
