دستگاه فرستنده گیرنده رادیویی توان بالا YS-C30M
دستگاه فرستنده گیرنده رادیویی توان بالا YS-C30M یک مودم رادیویی مقرون به صرفه و عملکرد بالاست. این دستگاه در باند ISM و فرکانس 433 مگاهرتز کار می‌کند و توان خروجی آن 2 وات است. مدولاسیون استفاده شده برای انتقال سیگنال مدولاسیون GFSK/FSK بوده و مقاومت خوبی در برابر نویز از خود نشان می‌دهد.
کاربردها
- ایستگاه اتوبوس
- سیستم‌های مخابراتی
- سیستم‌های امنیتی
- سنسورهای بی‌سیم
- کشاورزی هوشمند
ویژگی‌های محصول
با توجه به اهمیت مطالب فنی از ترجمه صرف نظر شده است.
- Low power transmission with 2W.
- With 433MHz as factory default carrier frequency, 400~470MHz is available if needed.
- High anti- interference and Low BER (Bit error Rate)
- Based on the Gaussian Frequency Shift Keying (GFSK) modulation, the high-efficiency forward error correction channel encoding technology is used to enhance data’s resistance to both transient interference and random interference and the actual bit error rate of 10-5 ~ 10-6 can be achieved when channel bit error rate is 10-2.
- Long Transmission Distance
- Within the visible range, when the height of antenna is higher than 2m and The Bit Error Rate (BER) is 10-3, the reliable transmission distances respectively is 7000m @1200bps, and is 5000m@9600bps.
- Transparent data transmission
- Transparent data interface used in transceivers is for meeting many standard or nonstandard user protocols. Any false data generated in air can be filtrated automatically(What has been received is exactly what has been transmitted).
- Multi-channels
- YS-C30M transceivers offer 8 channels, if needed, 16 or 32 channels are available to satisfy various configuration of communication under user’s demand at the same time.
- 2 ports with three connection methods
- YS-C30M transceivers provide 2 ports with three connections, ports: a UART interface of TTL level, a non-standard RS-232 port and a non-standard RS-485 port. USB interface port is also available if needed.
- Big data buffer area
- With optional interface baud rate: 1200/4800/9600/19200 bps and 8N1/8E1/8O1 data format (set by user), the transceiver can transmit unlimited data frames with flexible user program.
- Note: the RF data rate is only settled down before delivery, please inform our sales when placing your orders.
- Intelligent data control and no any extra programs required
- Even for half duplex communication, no any excessive programs required. All RF system data transmission/reception and other On-the-Fly conversion and control are performed by YS-C30M transceivers automatically.
- Lower power consumption & Sleep function
- With +5V power, the receiving current is less than 30mA, the transmitting current is less than 1.5A, and the sleeping current is less than 20uA.
- High reliability, small and light
- By using monolithic radio-frequency integrated circuit and single-chip MCU, the
- transceivers have less peripheral circuit s, high reliability, and low failure rate.
- More options of configurable antennas for user different applications.
- Watchdog monitor
- Watchdog monitors the inner function, so it can change the traditional product structure and also improve the reliability of our modules.
- With beautiful metal shell.
|
|
